UNIC URW-095 Spider Crane – RT – NA – Petrol – LPG – RCU

Download Technical PDF

At A Glance

Max Working Height

8.8

Reach

8.41

Weight

1 850

See full specification

Description

At 0.6m wide, the UNIC 095 mini crane is specifically designed for interior access and yet benefits from class-leading lifting capacity.

The Unic 095 Crawler crane boasts unrivalled boom length and its outriggers allow for independent, multi-angle configurations to suit the working space.

Capacity 0.995t x 3.5m
Total width 0.6m
Max working radius 8.41m
Max boom length 8.65m
Petrol powered, optional LPG dual, electric dual and diesel
Zero length increase with electric option (except diesel
Multi-position configurable outriggers
Intelligent voice warning system
Overload warning device senses outrigger displacement
Radio remote control as standard
Eco Intelligent throttle activation for economy and ecology

Additional Information

Height (mm)	1380
Capacity (t)	0.995
Max Working Height (m)	8.8
Weight (kg)	1850
Reach (m)	8.41
Max Load (kg)	2900
Width (mm)	600
